Drop Decks & Wideners 2024 Haulmore 3x4 Drop Deck Widening Trailer
13.7 m drop-deck widening semi with bi-fold ramps and 500 mm beavertail
Haulmore 3 X 4 Drop Deck Widening Semi Trailer 13.7m Drop deck widener 2.5 to 3.5 mtr Bi fold ramps (2.8 & 1.5) 500mm beavertail. K HITCH 20″ 10 stud 285 pcd drum brake axles – Parallel bearings K HITCH 2.7m 9 leaf suspension Air Brake to ADR 38/04 compliance – Brake Kit EBS LED lights Steel construction (Grade 700 HT plate) YANMAH Diesel power pack, manual hydraulic controls (Engine mounted LHS gooseneck, 2 speed wind down landing legs 2 under-deck tool boxes & 1 water tank 2 winch type tyre carriers 13 wheels 55/70R X 22.5 Triangle tyres Pull out ramps to top deck (or flip over) Front Load rack Twistlock positions and stands Grit-blasted and painted in 2 pack paint to your requirements.
Spin the Build
Dimensions
| Deck length | 13.7m drop deck widener |
|---|---|
| Deck width | 2.5 to 3.5 m (widening) |
Running Gear
| Stud count | 10 stud |
|---|---|
| PCD | 285 pcd |
| Axle make | K HITCH |
| Suspension | K HITCH 2.7m 9 leaf suspension |
| Leaf count | 9 leaf |
| Axle configuration | tri-axle (3x4) |
| Axle count | 3 |
Braking & Electrical
| Brake system | Drum brake |
|---|---|
| ABS/EBS | EBS |
| Lighting | LED |
Deck & Body
| Deck/chassis material | Steel construction (Grade 700 HT plate) |
|---|
Compliance
| Brake compliance | ADR 38/04 |
|---|
Key features
- Haulmore 3 X 4 Drop Deck Widening Semi Trailer, PRICE: POA
- K HITCH 20″ 10 stud 285 pcd drum brake axles – Parallel bearings
- K HITCH 2.7m 9 leaf suspension
- Air Brake to ADR 38/04 compliance – Brake Kit EBS
- Steel construction (Grade 700 HT plate)
- 2 speed wind down landing legs
- 2 under-deck tool boxes & 1 water tank
- 2 winch type tyre carriers
Built for
- Machinery transport
- Oversize freight
